| CCD.17.EX140 |
USB CCD 1.4MP Camera |
| Sensor Model |
SONY ICX285AQ |
| Scan Mode |
Progressive |
| Max. Resolution |
1360X1024 (Approx. 1,400,000 Pixels) |
| Sensor Size |
2/3" (10.2mm(H) x 8.3mm(V), Diagonal 11mm) |
| Pixel Size |
6.45µm x 6.45µm |
| G Sensitivity |
1240mV with 1/30s Accumulation |
| DynamicRange |
70dB |
| A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
| SN Ratio |
62dB |
| Spectral Range |
400-650nm (with IR-filter) |
| Frame Size and Rate |
15fps @1360 x 1024(Multiple Speed Level) |
| Binning |
1 x 1 |
| Exposure |
Normal Exposure: 0.126~66.695ms, ROI Auto & Manual Long Exposure: 66.695ms~4mins |
| Color Rendering Technique |
Ultra FineTM Color Engine |
| White Balance |
One Push ROI White Balance/Manual Temp-Tint Adjustment |
| Capture/Control API |
Native C/C++ SDK, DirectShow, Twain |
| Capture Mode |
Still Picture and Video |
| Software Environment |
| Operating System |
Microsoft® Windows® XP / Vista / 7 (32 & 64 Bit)
OS X (MAC OS X)
Linux (Kernel 2.6 or Above) |
| PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or Higher |
| Memory:2GB or More |
| USBPort:USB2.0 High-speed Port |
| Operating Environment |
| Operating Temperature |
-10~60℃ |
| Storage Temperature |
-30~80℃ |
| Operating Humidity |
30~80%RH |
| Storage Humidity |
10~60%RH |
| Power Supply |
Over USB Port |
